FR-4 Multilayer PCB 94V-0 Lead Free ENIG Gold Finger Circuit Board

Shenzhen Xinchenger Electronic Co.,Ltd
Contact Now

FR-4 Multilayer PCB 94V-0 Lead Free ENIG Gold Finger Circuit Board

  • 1
  • 2

Brand Name : XCEPCB

Model Number : XCEPCBR

Certification : CE,FCC,ISO9008,SGS,UL

Place of Origin : CHINA

MOQ : 1pcs

Price : USD 0.1-10

Payment Terms : Western Union,, T/T

Supply Ability : 1000000PCS/per week

Delivery Time : 3-12 days

Packaging Details : Inner:Vacuum packed bubble bag Outer:Carton box / mentioned is standard packing method,unless otherwise specified.

Material : FR4 PCB

Color : GREEN

Size : 9*6cm

Surface : HASL

Board THK : 1.6mm

Copper THK : 1OZ

Layer : 4

Core : 2pcs

Contact Now

FR-4 Multilayer PCB 94V-0 Lead Free ENIG Gold Finger Circuit Board Manufacturer in China

v Fast PCB Fabrication for Samples and Mass Production

v Electronic Components Sourcing Services

v PCBA Assembly Services:SMT,DIP,BGA...

v Function Test

v Stencil,Cable and Enclosure Assembly

v Reverse engineering service

v Standard Packing and On time Delivery

Specifications

Capability

Standard

Advanced

Minimum Layer Count

1

1

Maximum Layer Count

12

40

Material

FR-4 (Tg-135C, 145C, 170C), Halogen- free

Rogers Ultralam 2000, Rogers RO4350, Rogers RO4003

Polyimide

Teflon

Black FR-4

Arlon AR-350

CEM-3

Getek Copper Clad Thermal Substrates

Hybrid (Rogers and FR4) BT Epoxy

Nelco 4013

PTFE

Metal Core Materials

Aluminum Core

Board Thickness

0.020"-0.125"

0.005"-0.250"

Maximum Board Size

16" x 22"

12" x 21"

22" x 28"

10" x 16"

16" x 22"

12" x 21"

22" x 28"

Copper Thickness

0.5 oz 3 oz

0.25 oz 12 oz

Minimum Trace Width / Spacing

0.004"/0.004"

0.003"/0.003"

Solder Mask Color

Green, Blue, Black, Red, Yellow, White, Clear, and customized

Silkscreen Color

White, Black, Yellow, Green, Red, Blue and customized

Minimum Hole Size

0.008"

0.004"

Finished Hole Size Tolerance

+/-0.003"

+/-0.002"

PCB Surface Finish

HASL (vertical & Horizontal), Lead Free HASL, OSP/Entek, ENIG, ENEPIG,

HASL + Gold Finger,Immersion Tin(ISn), Immersion Silver(IAg), Carbon

Ink, Hard Gold(Flash Gold), Soft Gold

IPC Class

Class 2

Class 3

Controlled Impedance Tolerance

+/-10 %

+/-5 %

Blind Vias

Yes

Yes

Buried Vias

Yes

Yes

Aspect Ratio

8/1

15/1

Minimum Core Thickness

0.004"

0.002"

Carbon Ink

Yes

Yes

Peelable Mask

Yes

Yes

Solder Sample

Yes

Yes

First Article

Yes

Yes

ISO 9001: 2008

Yes

Yes

ISO/TS16949: 2009

Yes

Yes

UL 94v0

Yes

Yes
